Nano silver spray automatic line robot special automatic spray gun

Model:: A-S2-C2

USD Unit Price:: 200

MOQ:: 10Pcs

Payment:: Cash on delivery

Delivery Time:: Lssued in 2 hours

Inquire Online
Download

Cancel

PRODUCT FEATURES

According to the viscosity of the selected fluid and the total requirements of the products we spray, the spray gun caliber can be selected from the following caliber 0.5~2.0mm. The air cap of the spray gun can be selected from round or fan-shaped. The circular angle is generally 15°, and the angle of the fan-shaped cap is generally standard 45°, 60° and 90°. The fan-shaped nozzle spray gun is not locally affected during the installation process and can be installed at any position where the air compressor can be connected.

PRODUCT PARAMETER

Model	Feed Type	Nozzle Size (mm)	Air Pressure (MPa)	Air Consumption (1/min)	0utput (ml/min)	Spray Width	Color
A-S2-C2-08P	Pressure feed	0.8	0.35-0.6	650	400	320	Blue/Color
A-S2-C2-10P		1		680	600	380
A-S2-C2-13P		1.3		750	850	515
A-S2-C2-15P		1.5		800	1100	980
A-S2-C2-18P		1.8		820	1350	1200
A-S2-C2-20P		2		860	1450	1550
Nozzle* needle material:316 stainless steel				Gun body material: aluminum alloy

Classic case

● Surface treatment of daily necessities such as heels

● Car modification/personalized production of car wheels

● Surface spraying of handicrafts/surface spraying of jewelry

● Spray plating on casings of mobile phones/lightings and other household appliances...

Spray gun features

1. The material of nozzle, needle and liquid passage are 316 stainless steel, so it could spray both ordinary paint and kinds of liquids.
2. As manufactured by machine after birthed from the mold, it is of good quality.
3. Every gun has its only code in the gun body, it is helpful for tracking and service after sales.
